Belden 1192A Cable 24 AWG 4 Conductors Microphone Star Quad Low Impedance Stranded 42x40 PVC Jacket Cable

Description:
• 24 AWG stranded (42x40) high-conductivity bare copper conductors, polyethylene insulation, tinned copper braid shield (95% coverage), PVC jacket.

Insulation:
• Material: PE - Polyethylene
• Wall Thickness (in.): 0.016
• Diameter (in.): 0.056

Outer Jacket:
• Material: PVC - Polyvinyl Chloride

Mechanical Charactertistics (Overall):
• Operating Tempeature Range: -30°C To +75°C
• Non-UL Temperature Rating: 75°C
• Bulk Cable Weight: 33 lbs/1000 ft.
• Max. Recommended Pulling Tension: 21 lbs.
• Min. Bend Radius/Minor Axis: 2.500 in.

Applicable Specifications and Agency Compliance (Overall):
Applicable Standards and Environmental Programs:
• EU Directive 2011/65/EU (ROHS II): Yes
• EU CE Mark: Yes
• EU Directive 2000/53/EC (ELV): Yes
• EU Directive 2002/95/EC (RoHS): Yes
• EU RoHS Compliance Date (mm/dd/yyyy): 01/01/2004
• EU Directive 2002/96/EC (WEEE): Yes
• EU Directive 2003/11/EC (BFR): Yes
• CA Prop 65 (CJ for Wire and Cable): Yes
• MII Order #39 (China RoHS): Yes

Electrical Characteristics (Overall):
• Nom. Characteristic Impedance (Ohm): 40
• Nom. Inductance (μH/ft): 0.21
• Nom. Capacitance Conductor to Conductor (pF/ft): 39.2
• Nom. Cap. Between Cond. in a Quad Config. (pF/ft): 57.4
• Nominal Velocity of Propagation: VP (%): 66
• Nom. Conductor DC Resistance @ 20°C (Ohm/1000 ft): 26.6
• Nominal Outer Shield DC Resistance @ 20°C (Ohm/1000 ft): 7.1
• Max. Operating Voltage - UL: 100 V RMS
• Max. Operating Voltage - Other: 18.0 kV (Nom. breakdown voltage between conductors)
• Max. Operating Voltage - Other: 16.9 kV (Nom. breakdown voltage conductors to shield)
• Max. Recommended Current: 2.9 Amps/Conductor @ 25°C

Plenum/Non-Plenum:
• Plenum (Y/N): No
