Product Details
Bare copper conductors, PVC insulation, Gray PVC jacket with rip cord. Sequential footage marking every two feet.
Applications:
• Addressable Fire Systems
• Data Circuits
• Monitor/Detection
• Control Circuits
• Initiating Circuits
• Notification Circuits
Benefits:
• Unsurpassed quality and reliability
• Wide range of standard options
• Custom solutions available upon request
Features:
• NEC riser and plenum rated; UL and C(UL) listed as applicable
• Rip cords for easy jacket removal; sequental footage markings on the jacket to eliminate guesswork and waste
• A unique composite cable design, Access Control Banana Peel strips away installation time and labor
| technical specification: | |
| awg | 18 |
| no. of cond. | 2 |
| stranding | solid |
| standard lengths (ft.) | c-500 |
| standard lengths (m) | c-152 |
| standard unit weight (lbs.) | 7.5 |
| standard unit weight (kg ) | 3.4 |
| outer jacket thickness (inch) | .015 |
| outer jacket thickness (mm) | .38 |
| nominal od (inch) | .151 |
| nominal od (mm) | 3.84 |
| belden cable part number | 5320UE |
