Belden 1094A 18 AWG 8 Triads 600V Tray Cable
Overall Cabling Lay Length and Direction:
• Length (mm): 231.393089
• Twists (twist/m): 4.33092
Pair Lay Length and Direction:
• Lay Length (mm): 63.5
• Twists (twist/m): 15.749
Mechanical Charactertistics (Overall):
• Bulk Cable Weight: 463.574 Kg/Km
• Max. Recommended Pulling Tension: 2989.190 N
• Min. Bend Radius/Minor Axis: 190.500 mm
Electrical Characteristics (Overall):
• Nom. Inner Shield DC Resistance @ 20°C (Ohm/km): 23.3279
| technical specification: | |
| awg | 18 |
| # triads | 8 |
| stranding | 7x26 |
| no. of conductors | 24 |
| conductor material | bare copper |
| outer shield - type | tape |
| outer shield - material | aluminum foil-polyester tape |
| overall cable- nominal dia. (mm) | 18.923 |
| belden cable part number | 1094A |
