Product Details
Mechanical Charactertistics (Overall):
• Bulk Cable Weight: 180.072 Kg/Km
• Max. Recommended Pulling Tension: 1112.050 N
Applicable Specifications and Agency Compliance (Overall):
Applicable Standards and Environmental Programs:
• NEC/(UL) Specification: CMG, ITC-ER, PLTC-ER
Electrical Characteristics (Overall):
• Nom. Capacitance Cond. to Other Conductor and Shield (pF/m): 190.298
• Nom. Conductor DC Resistance @ 20°C (Ohm/km): 12.0413 (16 AWG)
• Nominal Outer Shield DC Resistance @ 20°C (Ohm/km): 10.1711
| technical specification: | |
| awg | 16 |
| # pairs | 3 |
| stranding | 7x24 |
| no. of conductors | 7 |
| conductor material | bare copper |
| outer shield - type | tape |
| outer shield - material | aluminum foil-polyester tape |
| overall cable- nominal dia. (mm) | 11.430 |
| belden cable part number | 1528A |
