Insulation:
• Trade Name: Teflon®
• Wall Thickness (mm): 0.254
Inner Shield Drain Wire AWG:
• Stranding: 16x34
Outer Jacket:
• Trade Name: Teflon®
• Material: FEP - Fluorinated Ethylene Propylene
• Nom. Wall Thickness (mm): 0.3556
Mechanical Charactertistics (Overall):
• Operating Temperature Range: -70°C To +200°C
• Bulk Cable Weight: 37 lbs/1000 ft.
Electrical Characteristics (Overall):
• Nom. Characteristic Impedance (Ohm): 50
• Nom. Capacitance Conductor to Conductor (pF/ft): 31
• Nom. Capacitance Cond. to Other Conductor & Shield (pF/ft): 67
• Nominal Velocity of Propagation (VP %): 69
| technical specification: | |
| awg | 22 |
| # pairs | 3 |
| stranding | 7x30 |
| no. of conductors | 6 |
| conductor material | tinned copper |
| dia. (mm) | 0.762 |
| outer shield - material | unshielded |
| overall cable- nominal dia. (mm) | 5.944 |
| belden cable part number | 88777 |
